SikaWall®-161 Plaster Mix

SikaWall®-161 Plaster Mix

PLASTER AND BRICK ADHESIVE

SikaWall®-161 Plaster Mix is a one component, pre-packed polymer modified mortar combining cement with selected grades of sand and several admixtures; used as light brick plaster, red brick plaster, and red brick adhesive.

  • Multi function for plaster and brick adhesive
  • Excellent adhesion
  • Prevents hair cracks caused by material shrinkage
  • More efficient, only 5 - 10 mm thickness for plaster and ~ 10 mm thickness for brick adhesive application
  • Easy to use and apply, just add water
Show all documents

Usage

For plaster can be applied on various surface, such as :
  • Light brick and red brick surface.
  • Concrete surface that have been treated with bonding agent (e.g. Sika Latex® or SikaBond® NV)
  • For non-exposed application


Advantages

  • Multi function for plaster and brick adhesive
  • Excellent adhesion
  • Prevents hair cracks caused by material shrinkage
  • More efficient, only 5 - 10 mm thickness for plaster and ~ 10 mm thickness for brick adhesive application
  • Easy to use and apply, just add water

Packaging

40 kg bag

Colour

Powder / Grey

Product Details

Product Information

Shelf life

9 months from date of production if stored properly in original, unopened and undamaged sealed packaging.

Storage conditions

Store in dry conditions at temperatures between +5 °C and +30 °C.

Density

~1.65 kg/L
Technical Information

Compressive strength

28 days

~6 N/mm2

Tensile adhesion strength

28 days

~0.3 N/mm2

Application

Application Information

Mixing ratio

Water : SikaWall®-161 Plaster Mix

6 - 6.4 L : 40 kg (by weight)

Water : SikaWall®-161 Plaster Mix1 : ± 3.5 (by volume)



Layer thickness

For red brick laying : ~ 10 mm (max. thickness 15 mm)
For plastering : min. 5 mm (max. thickness 15 mm)

Ambient air temperature

+8 °C to +40 °C

Pot Life

~1 hours (at +30 °C)

Waiting time to overcoating

As brick adhesive before plaster - after 24 h*
As plaster before skim coat - after 7 d*

*Note : Times are approximate and will be effected by changing ambient conditions particulary temperature and relative humidity. Low temperature and high relative humidity retard curing, while high temperature and low relative air humidity accelerate curing progression.
Consumption

Consumption

Red Brick Adhesive :
~1.25 m2 per 40 kg bag (based on 10 mm thickness)*
Plaster :
Light brick :

~4 m2 per 40 kg bag (based on 5 mm thickness)*
*depend on substrate surface profile and layer thickness
Application steps

MIXING

  • Pour 6 - 6.4 Litre of water into mixing vessel then add SikaWall®-161 Plaster Mix slowly and mix properly
  • Mixing time is ~3 minutes. A slow speed mixer is recommended (300 - 600 rpm)


APPLICATION

As Brick Adhesive

  • Apply with scoop then fix the brick. Proceed to apply while SikaWall®-161 Plaster Mix is still wet.
  • Waiting time before plaster application minimum 24 hours. To get the best result use SikaWall®-161 Plaster Mix.



As Plaster

  • Apply with flat trowel.
  • Waiting time before skim coat application minimum 7 days. To get the best result use SikaWall®-181 SkimCoat.

CLEANING OF EQUIPMENT

Clean all tools and application equipment with water immediately after use.

Hardened / cured material can only be mechanically removed.
